Tutorial 06: Seismic AVO Forward Modeling

Tutorial 06: Seismic AVO Forward Modeling#

Note

This tutorial is available as a Python script examples/06_seismic_avo_forward.py and an interactive Jupyter notebook examples/notebooks/06_seismic_avo_forward.ipynb.

Generate pre-stack seismic angle gathers from geological models through rock physics and AVO reflectivity.

What You Will Learn#

  • End-to-end workflow: porosity → velocities → reflectivity → seismic

  • Use compute_reflectivity for angle-dependent AVO modeling

  • Build convolution matrices with create_conv_matrix

  • Generate synthetic pre-stack angle gathers

Key Concepts#

AVO (Amplitude Variation with Offset) analysis exploits the fact that reflection amplitudes change with incidence angle, providing information about fluid content and lithology.

Code Highlights#

from geobrain.physics.wave import RickerWavelet, compute_reflectivity, create_conv_matrix

# Angle-dependent reflectivity
refl = compute_reflectivity(vp1, vs1, rho1, vp2, vs2, rho2,
                            theta=[12, 24, 36], method='shuey')

# Wavelet convolution
ricker = RickerWavelet()
wavelet, _ = ricker(f0=25.0, dt=0.001)
W = create_conv_matrix(wavelet, n_samples)
seismic = refl @ W[nsW:-nsW].T

Results#

../_images/06_ricker_wavelets.png

Fig. 46 Ricker wavelets at different dominant frequencies.#

../_images/06_rock_properties.png

Fig. 47 Elastic property fields: Vp, Vs, density.#

../_images/06_angle_gathers.png

Fig. 48 Synthetic pre-stack seismic angle gathers.#

Full Example#

See examples/06_seismic_avo_forward.py.
